BlastBlock soundproofing materials

BlastBlock is a mass loaded vinyl (MLV) soundproofing membrane weighing nominally 5 kg/m² at approximately 3 mm thick. Manufacturer data, reference BB830/20/v2, gives STC 32 for the material alone and up to STC 68 in a double-stud assembly with mineral wool. It installs in walls, ceilings, floors, ductwork and machine enclosures, and cuts with a utility knife. Stock is held in Bangkok.

Those are laboratory values. Field performance is normally lower — see the STC table by wall build-up.

Mass loaded vinyl

• BB830

  BlastBlock MLV BB830

  ฿1,122incl. VAT · ฿1,049 excl. VAT

  Sold in whole 5 m² rolls only

• BB830FR

  BlastBlock MLV BB830FR fire-rated

  ฿1,288incl. VAT · ฿1,204 excl. VAT

  Sold in whole 5 m² rolls only

• BB830LF

  BlastBlock MLV BB830LF low-frequency

  ฿1,761incl. VAT · ฿1,646 excl. VAT

  Sold in whole 5 m² rolls only

• BB830-TRIAL

  BlastBlock MLV BB830 — 1 m² trial piece

  ฿1,122incl. VAT · ฿1,049 excl. VAT

Installation accessories

Performance is decided by how completely the assembly is sealed. An open area of roughly 1% of a wall can cap transmission loss at around 20 dB whatever the build-up, which is why sealant, adhesive and putty pads are not optional extras.

• BB460

  BlastVib BB460 sound damping

  ฿8,688

• BA890

  BlastSealant BA890

  ฿321

• BA990

  BlastAdhesive BA990

  ฿428

• BA650

  BlastPutty BA650 firestop acoustic putty pad

  ฿385
