BB830 MLV
Soundproofing, Noise Stopper , Blocks Noise, Improve Transmission Loss
Description
High-performance noise insulation for both new and old situations is called BlastBlock.
BlastBlock is a mass-loaded vinyl that has been acoustically optimized to block sound and contains extra aluminum. It is strong, flexible, and simple to install. Dutch engineers were involved.
Soundproofing Applications
• Sound barrier
• Meeting room
• Wall panel
• Ceilings
• Floors
• Home theatre
• Pipes
• Ducts
Physical Properties:
• Weight 4.9 kg per square meter
• Tensile strength min. 510 PSI
• Colour black (high UV resistance)
• Composition: Proprietary Acoustically optimized mass loaded vinyl-based compound
• Flammability MVSS 302 – Passes; SAE J 369 passes 2.6” per minute
Other benefits:
- 100% Recyclable
- Highest Mold Resistance Rating
- High Acoustical Performance Ratings
- Good heat and fire resistance elasticity and tensile strength.
- No manufacturing emissions, no waste pollution, environmental protection and can be recycled several times.
- BlastBlock is a non-toxic flexible acoustic material that is easy to install and can be easily cut on-site with a regular utility knife.
- soundproofing, very strong and flexible, easy to install.
BlastBlock BB830 Acoustic Noise Insulation
| Product | BB830, BlastBlock Soundproofing |
| Material | Acoustically optimized Mass loaded vinyl, Aluminium |
| Colour | Black |
| Size | 1000 mm x 5000 mm |
| Thickness | 1 mm / 3 mm |
| Weight | 2.0 kg / 4.9 kg /m2 |
| STC Transmission Loss (dB) | 19 dB / 32 dB |
| Heat tolerance (°C) | 93 °C |
| UV resistant | Yes |
Acoustic performance for BlastBlock
| Frequency (Hz) | 125 | 250 | 500 | 1000 | 2000 | 4000 | STC |
| 1 mm | 5 | 9 | 15 | 21 | 26 | 34 | 19 |
| 3 mm | 16 | 25 | 34 | 36 | 34 | 45 | 32 |
| ASTM E90 Sound Transmission Loss dB |
Please click here to download this product datasheet
